New for DC 12V High Output Air Ionizer Airborne Negative Ion Anion Generator DIY

Description:

Working Principle:

By using pulses and vibration of electric appliances, rise the original low voltage to for DC high negative pressure. Making use of for DC high voltage of carbon brush tip to produce high corona, emitting large amounts of electronic at a high speed. Electronics can not remain in the air for a long for time, therefore,after reacting with oxygen molecules in the air , negative ions will form.

Features:

brand new and high quality

Can increase the oxygen content of the room,for play the role of for fresh air.

Can eliminate secondhand smoke from the air, pollen, dust etc.

Has the function of for health care: Improve sleep, promote the new supersedes the old, the body, and so did the human immune functions.

Specification:

Type: Double-headed with bracket

PK-D12F

Power Supply: Car Power

Applicable Area: 11㎡-20㎡

Air Purifier Volume: 50m³/h

Input voltage: DC12V

Output voltage: DC-3.5KV1.0KV

Negative ion concentration: ≧4x106PCS/cm³(Test at 100mm)

Insulation resistance: ≥40MΩ(500V for DC)

Dielectric Strength: AC3000V 50Hz 5mA

Rated Power: ≤1W

Input Current: ≤20mA

Ozone Concentration: ＜0.05PPM

Working Temperature: -10℃~50℃

Working Humidity: 35%~85%

Storage Temperature: -20℃~50℃

I/P: D12V Red:+ Black:-

O/P: -DV2.0~6.0KV

Material: ABS+Silicone Line

Dimensions: 27x15x18mm/1.06x0.59x0.71''(approx)

Color: Black

Quantity: 1 pc

Note:

Transition: 1cm=10mm=0.39inch

No retail package.

Please allow 1-3mm error due to manual measurement. pls make sure you do not mind before you bid.

Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!

Package includes:
