Digital Power Meter Wattmeter 100A 6 in 1 Electricity Usage Monitor Voltage Voltmeter Ammeter Socket Tester Energy Meter

Features:

This combo meter is designed to monitor AC power, it combines many functions in one.

Backlight control, short press to turn on/off backlight, Automatically save data when power is turned off in backlight state.

Clear energy reading, press and hold down the for key to clear the reading of kWh.

With Overload alarm, Power alarm threshold preset, Store data, Reset function

Measurement precision, large-screen LCD liquid crystal screen display clearly.

Function:

1. Electrical parameter measurement function (voltage, current, power factor, power, Hz, Energy).

2. Overload alarm function (over power alarm threshold, the backlight and power flicker tips).

3. The power alarm threshold preset function (can set up their own power alarm threshold).

4. The power button clear function.

5. Power-down data storage function.

6. Large-screen LCD screen full display function (display voltage, current, active power, power).

7. Backlight.

Parameters:

Voltage Measuring Range: 80-260V

Current Measuring Range: 0-100A

Frequency Measuring Range: 45-65Hz

Power Factor Measuring Range: 0.00-1.00PF

Power Measuring Range:0-22000W, Starting power: 0.5W

Energy Consumption Measuring Range: 0-999kWh

Specification:

Current types: 100A

Power supply: 80~260V AC

Display type: LCD

Sensor type: Split Current Transformer

for Shell material: Reinforced nylon

Dimensions: 89.6x49.6mm/3.53x1.95inch

Color: Black

Quantity: 1 Set

Package includes:

1 x Power Energy Monitor

1 x Split Current Transformer
